Title: Magnetic Core Selection for Transformers & Inductors : A User's Guide to Practice and Specification Author: William T. McLyman ISBN: 0824798414 / 9780824798413 Format: Hard Cover Pages: 672 Publisher: Marcel Dekker Year: 1997 Availability: In Stock
Description
Contents
Written as a companion to the highly acclaimed Transformer and Inductor Design Handbook, Second Edition (Marcel Dekker, Inc.), this timely new edition of Magnetic Core Selection for Transformers and Inductors compiles the specifications of over 12,000 industrially available cores and brings them in line with standard units of measurements - simplifying the selection of core configurations for the design of magnetic components.
Foreword
Preface
Acknowledgments
Manufacturers
Symbols
Useful Transformer and Inductor Design Equations
Decimal and Millimeter Equivalents
Chapter 1 : Magnetic-Core Power-Handling Ability Chapter 2 : Transformer Output Circuits Chapter 3 : Transformer and Inductor Design Examples Chapter 4 : Magnetic-Core Material Trade-Off Chapter 5 : Conversion Data for Magnet Wire Chapter 6 : Cased Toroids Chapter 7 : High Flux, MPP, SENDUST, KOOL Mµ, and Iron Powder Cores Chapter 8 : Ferrite Cores Chapter 9 : Laminations Chapter 10 : C Cores Chapter 11 : Caseless Toroids Chapter 12 : E Cores Chapter 13 : PC Board Mounts/Headers and Transformer Mounting Brackets
